MSI B850 Gaming Plus WiFi 6E DDR5

The MSI B850 Gaming Plus WiFi 6E DDR5 is a high-end ATX motherboard for AMD Ryzen 7000/8000/9000 CPUs with AM5 socket. It supports up to 256GB DDR5 RAM (8200+ MHz OC), PCIe 5.0 graphics, three M.2 slots (Gen5/Gen4), 5 GbE LAN, Wi-Fi 7, multiple USB Type-C ports, and strong power delivery—perfect for advanced gaming and content creation.

₨. 37,999
1
Specifications
Specifications
CPU SupportAMD Ryzen 7000/8000/9000 series desktop processors on AM5 socket.
ChipsetAMD B850.
Memory4 DDR5 DIMM slots supporting up to 256GB of RAM with speeds from DDR5-4800 up to 8200+ MT/s (OC). Dual-channel memory architecture with AMD EXPO support.
Expansion Slots
  • - 1 x PCIe 5.0 x16 slot (from CPU),
  • - 1 x PCIe 4.0 x8 slot (depending on CPU),
  • - 2 x PCIe 3.0 x1 slots.
Storage
3 x M.2 slots
M2_1PCIe Gen5 x4 (up to 128Gbps) with EZ M.2 Shield Frozr II for thermal management,
M2_2PCIe Gen4 x4,
M2_3PCIe Gen4 x2 from chipset, - 4 x SATA 6Gbps ports, - RAID 0 and 1 support for M.2 NVMe and SATA devices.
Networking
  • - Realtek 5 GbE LAN,
  • - Integrated Wi-Fi 7 (latest generation) with Bluetooth 5.4,
  • - MSI EZ Antenna for improved wireless reception.
USB Ports
  • - Rear I/O includes USB 3.2 Gen 2 (10Gbps) Type-C and Type-A,
  • - Multiple USB 3.2 Gen 1 (5Gbps) and USB 2.0 ports,
  • - Front panel USB 3.2 Gen 2 Type-C header.
AudioRealtek ALC897 7.1-channel HD Audio with Audio Boost for higher sound fidelity.
Display OutputsDisplayPort 1.2 supporting up to 4K at 60Hz (with integrated graphics).
Power Delivery
  • - 12+2+1 Duet Rail Power System for stable CPU power,
  • - Dual 8-pin CPU power connectors,
  • - Extended heatsinks with high thermal conductivity MOSFET pads (7W/mK),
  • - Extra thermal pads on chokes for enhanced cooling.
Cooling and DIY Features
  • - EZ M.2 Shield Frozr II with tool-less M.2 SSD installation,
  • - EZ PCIe Clip II for easy GPU removal,
  • - Extended heatsinks for VRMs, MOSFETs, and chipset,
  • - Multiple fan headers including CPU, water pump, and system fans.
Other Features
  • - TPM 2.0 header support,
  • - Multiple RGB and ARGB LED headers,
  • - EZ Debug LEDs and clear CMOS and BIOS flashback buttons on rear I/O for troubleshooting and easy BIOS updates,
  • - MSI Surface Mount Technology to improve signal integrity,
  • - Supports Windows 10 and 11 (64-bit).
Form FactorStandard ATX (305mm x 244mm).
